10 piece (MOQ)
| Business Type | Manufacturer, Exporter, Supplier |
| Download |  View |
| Color | RAL7035 (Light Grey) |
| Material | Fiber-glass Reinforced Polymer |
| Click to view more | |
Product Details
Brand Name
Sumip
Clear Area Length
200 Mm
Uniformly Distributed Load
400 Kg
Flammability Rating
Low Flammability (UL-94)
Cable Support Width
300 Mm (A), 260 Mm (B)
U.V. Property
U.V. Stabilized
Model No.
BRO1PO12M
Cable Support
300x100x40 Mm
Moulding
Hot Press Moulded SMC- Machine Moulded
Features
- Nonmetallic
- Rust or Corrosion Free
- High Load Capacity
- No Grounding or Bonding
- Excellent Dielectric Properties
- Insulators are not required
Technical Specification
| Model No. | Cable Support Size (mm) | Cable Support Width (mm) A | Cable Support Width (mm) B | Clear Area Length (mm) C | Uniformly Distributed Load (Kg) |
| BRO1PO18M | 450x125x40 | 450 | 410 | 350 | 400 |
| BRO1PO24M | 600x150x40 | 600 | 560 | 500 | 400 |
| BRO1PO30M | 750x200x40 | 750 | 710 | 650 | 400 |
